Center Hole Cylinder/Ram – Single-Acting / Spring Return, 20 ton Capacity, 3.000 in Stroke, 6.063 in Retracted, 9.063 in Extended | RH203

RH203 CYL, 20 TON 3″ STROKE Center hole cylinder ideal for pulling and tensioning cables, anchor bolts with interchangeable piston head inserts Interchangeable piston head inserts (provide versatility of application) 12, 20, 30, 50, 60 Ton Single-Acting Models Feature Threaded Collar; Model RH203 and RHA306 do not feature the collar thread Withstands full “dead-end” loads Corrosion resistant standpipe has “Power Tech” treatment All cylinders except RH120 are furnished with a 9796 3/8″ NPT female half coupler Aluminum cylinder body and piston are featured on the RHA306 cylinder
